Wc67y/k-40/2000 Three – Cylinder CNC Hydraulic Press Brake Bending Machine

Product Description

The performance of this type of hydraulic press brake(metal sheet bending machine):

Model: serial WC67y/k

1. the frame is steel-welded construction, vibration to eliminate stress. With high strength and good rigidity.

2. forcing torsion bar maintains synchronization for the two pistons,with the higher parallelism to the table. Mechanical stop nuts ensure stable and reliable positioning accuracy.

3. The stroke(Y) of ram and (X) back gauge are all controlled by E20 NC or DA-41 system with high positioning precision.

4. Balls crew is equipped to ensure the positioning precision of back gauge.

E20 NC and DA-41 system has a simple programming function.

Line transducer is equipped also.

OPTIONAL:

1. two-hand control foot pedestal device

2. it is possible for special tooling with different lengths to bend the closed frame workpiece

3. crowned compensation device in worktable is available

4. any tailor-made are available on request.

Specification

FAQ

Q1. How to get an accurate quotation?

A1: The customer should provide the related technical requirements, drawings, pictures, industrial voltage, planned output,

Q2. What if I use this machine for the first time and know nothing of it ?

A2: We will have our engineers teach you how to operate it,you can just inform us some details of the product you need then we can customize as your special order.

Q3. How does your factory do regarding quality control?

A3: We has been regard quality as the priority. We always attach great importance to quality controlling from the very beginning to the very end ,so our press can match all the CE and ISO standard also more strict standard .

Q4. How about your delivery time?

A4: Generally, it will take 35 working days after receiving your deposit payment. The specific delivery time depends on the items and the quantity of your order. Sometimes we have standard machines in stock.

Q5. What is the warrantee period of the machine?

A5: We can supply 1 year warranty for our machines, We can send engineer to customer place if big quality problem. We can provide internet or calling service at any time.

Q6. After-sales service

A6: 1. Installation:Free installation and commissioning, travel expense is on foreign customer.(Including round ticket and
accommodation cost)
2. Personnel training: Our engineers will give your employees free machine training when they come to your company to assemble the machines, and welcome to our factory to learn how to operate our machine

Details

• Slider Stroke (mm): 100 mm
• Automatic Level: Fully Automatic
• Throat Depth (mm): 250 mm
• Machine Type: Torsion Bar, Press Brake
• Length of Working Table (mm): 2000
• Width of Working Table (mm): 100 mm
• Dimension: 2280*1470*2100
• Condition: New
• Material / Metal Processed: Carbon steel
• Automation: Automatic
• Extra Services: Machining
• Year: 2020
• Weight (KG): 2800
• Motor Power (kw): 4 kw
• Key Selling Points: Multifunctional
• Warranty: 1 Year
• Applicable Industries: Energy & Mining
• Showroom Location: UAE, Uzbekistan
• Marketing Type: New Product 2020
• Machinery Test Report: Provided
• Video outgoing-inspection: Provided
• Warranty of core components: 1 Year
• Core Components: Motor, Pump, Engine
• Raw Material: Sheet / Plate Rolling
• Power: CNC
• After-sales Service Provided: Engineers available to service machinery overseas, Video technical support, Online support
• Nominal Pressure (kN): 400
• Certification: ISO 9001:2000
• After Warranty Service: Video technical support, Online support
