Product Description:
1. The frame adopts whole welding structure, and by the fireplace tempering treatment, machine tool accuracy is good.
2. Hydraulic pressure type, step less pressure adjustment, using high quality imported sealing ring, to ensure the reliability of the machine tool.
3. Mechanical synchronization, using the upper and lower composite compensation structure, improve the machining accuracy of parts. (more than 160 tons for the working table compensation structure)
4. Adjust the slider stroke and adjust the position of the rear gear, use the electric quick adjustment and manual adjustment.
5. The machine tool is a little move, a single, continuous operation standard.
6. The machine tool is equipped with a safety protection bar and open door with power down device, which improves the safety ofoperation. (40 tons or more than 200 tons of no guard rails)
Specifications:
| Hydraulic press brake (Series WC67Y/K) | |||||||||
| Model | Pressure (KN) | Worktable length (mm) | Distance between columns (mm) | Depth of throat (mm) | Stroke (mm) | Max height between worktable and ram (mm) | Main motor (KW) | Weight (KG) | Dimension (LxWxH) (mm) |
| WC67Y/K-40/2500 | 400 | 2500 | 1925 | 220 | 80 | 300 | 4 | 3000 | 2650x1100x1950 |
| WC67Y/K-50/2500 | 500 | 2500 | 2015 | 220 | 100 | 340 | 4 | 3750 | 2650x1250x2100 |
| WC67Y/K-63/2500 | 630 | 2500 | 2015 | 250 | 100 | 340 | 5.5 | 4300 | 2650x1300x2200 |
| WC67Y/K-80/2500 | 800 | 2500 | 2010 | 250 | 120 | 380 | 5.5 | 5200 | 2560x1350x2250 |
| WC67Y/K-80/3200 | 800 | 3200 | 2510 | 250 | 120 | 380 | 5.5 | 6000 | 3260x1350x2280 |
| WC67Y/K-100/2500 | 1000 | 2500 | 2050 | 320 | 150 | 420 | 7.5 | 6700 | 2550x1360x2270 |
| WC67Y/K-100/3200 | 1000 | 3200 | 2550 | 320 | 150 | 420 | 7.5 | 7200 | 3260x1365x2520 |
| WC67Y/K-100/4000 | 1000 | 4000 | 3050 | 320 | 150 | 420 | 7.5 | 8500 | 4060x1365x2720 |
| WC67Y/K-125/3200 | 1250 | 3200 | 2550 | 320 | 150 | 420 | 7.5 | 7800 | 3260x1465x2600 |
| WC67Y/K-125/4000 | 1250 | 4000 | 3050 | 320 | 150 | 420 | 7.5 | 9000 | 4060x1460x2800 |
| WC67Y/K-160/3200 | 1600 | 3200 | 2590 | 320 | 200 | 475 | 11 | 10500 | 3260x1580x2775 |
| WC67Y/K-160/4000 | 1600 | 4000 | 3040 | 320 | 200 | 475 | 11 | 12500 | 4060x1580x2925 |
| WC67Y/K-160/6000 | 1600 | 6000 | 4800 | 320 | 200 | 480 | 11 | 19500 | 6060x1580x3480 |
| WC67Y/K-200/3200 | 2000 | 3200 | 2580 | 320 | 200 | 475 | 18.5 | 13200 | 3260x1650x2800 |
| WC67Y/K-250/4000 | 2500 | 4000 | 3130 | 400 | 250 | 530 | 18.5 | 19000 | 4060x1840x3150 |
| WC67Y/K-250/5000 | 2500 | 5000 | 3930 | 400 | 250 | 530 | 18.5 | 24000 | 5060x1840x3450 |
| WC67Y/K300/3200 | 3000 | 3200 | 2530 | 400 | 250 | 580 | 18.5 | 18000 | 3300x2100x2980 |
| WC67Y/K-300/4000 | 3000 | 4000 | 3200 | 400 | 250 | 580 | 18.5 | 22000 | 4060x2040x3330 |
| WC67Y/K-400/4000 | 4000 | 4000 | 3180 | 400 | 320 | 630 | 30 | 30000 | 4060x2220x3630 |
| WC67Y/K-400/6000 | 4000 | 6000 | 4700 | 400 | 320 | 630 | 30 | 45000 | 60602x2203x980 |
| WC67Y/K-500/6000 | 5000 | 6000 | 4600 | 500 | 320 | 70 | 30 | 55000 | 6080x2760x4000 |
| WC67Y/K-800/6000 | 8000 | 6000 | 4600 | 500 | 400 | 900 | 37 | 72000 | 6100x3250x4300 |
FAQ
1. What is the payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;Irrevocable LC at sight . When we receive the advance payment, we will start to make production.when the machine is ready , we will take pictures toyou.after we got your balance payment. we will send the machine to you.
2. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
3. When is the delivery time?
A: If the machine you will order is standard machine, we can ready the machine within 15days. if some special machines will be some longer. The ship time is about 30 days to Europe, America. If you are from Australia, or Asia, it will be shorter. You can place order according to delivery time and ship time.we will give you the answer accordingly.
4. What is your trade terms?
A : FOB, CFR,CIF or others terms are all acceptable.
5. What is your minimum order quantity and warranty?
A: MOQ is one set, and warranty is one year.but we will offer lifetime service for machine.
6. What is the package of the machines?
A: The machines standard will be packed in plywood case.
Details
- Slider Stroke (mm): 120 mm
- Automatic Level: Semi-automatic
- Throat Depth (mm): 200 mm
- Machine Type: Torsion Bar
- Length of Working Table (mm): 2500
- Width of Working Table (mm): 1600 mm
- Dimension: 2600*1700*2320
- Condition: New
- Material / Metal Processed: Stainless Steel, ALLOY, Carbon steel, Aluminum
- Automation: Automatic
- Extra Services: Cut To Length
- Year: 2021
- Weight (KG): 5000
- Motor Power (kw): 5.5 kw
- Key Selling Points: Competitive Price
- Warranty: 2 years, 2 years
- Applicable Industries: Machinery Repair Shops, Manufacturing Plant, Retail
- Showroom Location: Egypt, Canada, Brazil, Saudi Arabia, Pakistan, Mexico, Spain, UAE, Algeria, Romania, South Africa, Ukraine
- Marketing Type: New Product 2021
- Machinery Test Report: Provided
- Video outgoing-inspection: Provided
- Warranty of core components: 2 years
- Core Components: Bearing, Motor, Gear, PLC
- Opening Height: 350mm
- Raw Material: Sheet Metal Plate
- Name: Hydraulic Cnc Press Brake
- Product name: Magnetic Bending Machine
- Type: Hydraulic Bending Tools
- Function: Steel Metal Bending
- Keyword: Bending Machine Metal Steel Sheet
- Application: Stainless Plate Bending
- Table length: 2000/2500/3000/4000/5000mm
- Certification: CE ISO
- After-sales Service Provided: Free spare parts, Video technical support, Online support
- After Warranty Service: Video technical support, Online support, Spare parts
