✦Faster speed and higher accuracy
✦Fully automatic typesetting, 100% use of plates
✦More power saving, lower use cost
✦Send inquiry to get special discount!
Specification
| Item | MK-3015 |
| Working area | 3000x1500MM |
| X-axis travel | 1550MM |
| Y-axis travel | 3050MM |
| Z-axis travel | 120MM |
| X,Y positioning accuracy | ±0.05/1000mm |
| X,Y repeat positioning accuracy | ±0.03/1000mm |
| Acceleration | 1Gm/s² |
| Max running speed | 80m/min |
| Table load | 900Kg |
| Voltage | 380v/50Hz/60HZ |
Main Configuration
Raytools Laser Head
We can provide all high quality laser heads on the market. It's been tested by us for a long time.
Laser Source
Raycus/Max/IPG, multiple choice, Different brands, different laser power are available. The higher power, the thicker cutting thickness.
Servo Motor
By adding and improving vibration suppression function, it can improve the following performance and shorten the setting time.
Cypcut Control System
can remotely control computers and machines, adjust parameters and solve problems. Efficiency- One PC can control several machines.
Taiwan HIWIN Guide& YYC Gear
Adopted Taiwan Hiwin linear guide rail,&YYC gear. high positioning accuracy, scroll guide, reduce wear to maintain accuracy for a longer time.
Aviation aluminum beam
Our equipment adopts aviation aluminum beam, which is lighter, more dexterous, and stronger, which comprehensively improves the cutting speed and accuracy of the equipment.
Our Services
✦We will give you 2 years warranty, so you don't have to worry about the after-sales.
✦We will also send you new parts if there's any parts broken by non-human issues.
✦Our after-sales team has more than 10 years of rich experience, giving you all-round guidance
Details
- Application: LASER CUTTING
- Applicable Material: Metal, Plexiglax, metal
- Condition: New
- Laser Type: Fiber Laser
- Cutting Area: 3000*1500mm
- Cutting Speed: 120m/min
- Graphic Format Supported: AI, PLT, BMP, DXP
- Cutting Thickness: 5MM
- CNC or Not: Yes
- Cooling Mode: WATER COOLING
- Laser Source Brand: RAYCUS
- Laser Head Brand: Raytools
- Servo Motor Brand: FUJI
- Guiderail Brand: HIWIN
- Control System Brand: Cypcut
- Weight (KG): 3000 KG
- Key Selling Points: High-accuracy
- Optical Lens Brand: Wavelength
- Warranty: 3 years
- Applicable Industries: Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
- Machinery Test Report: Provided
- Video outgoing-inspection: Provided
- Warranty of core components: 2 years
- Core Components: Laser Source
- Mode of Operation: Pulsed
- Configuration: gantry type
- Products handled: Sheet Metal
- Feature: Water-cooled
- Product name: Fiber Laser Metal Cutting Machine
- Keyword: Fiber Laser Cuting Machine
- Laser power: 500W / 1000W / 2000W / 3000W
- Function: Cutting Metal Materials
- Name: Automatic CNC Laser Cutting Machine
- Type: Fiber Lasr Cutting
- Cutting materials: Stainless Steel Carbon Steel Etc( Metal Laser Cutting Machine )
- Laser source: Germany IPG Fiber Laser
- Laser head: Raytools Laser Head
