Products Description
25 Tons Hydraulic Power Press Punching Machines are stronger and more feature packed than any gap frame press on the market today. More steel in the c-section of the frame reduces what is known as angular deflection under full stamping loads. Larger flywheel, higher energy rating point ABDC, connecting rods and ball screws. New cast slide body with digital die height indicator and large flanged upper die adapter plate. Slide guides are taper wedge design like our straight side presses to assure long die life during production runs.
The JH21- 200 ton GEN-2 (left) shows our standard I-PRESS control, side safety guards, t-stand run station and t-slotted bolster and slide for quick clamping of dies.
Standard Execution:
Heavy, one-piece welded steel frame is designed to resist deflection, providing more accurate stampings and longer die life.
Fast-response hydraulic overload relieves the pressure of a tonnage overload in milliseconds, stopping the press immediately andprotecting press and dies from damage.
Wet clutch and brake provide long life, very low maintenance, and high performance even at high single-stroking rates.
JIS I accuracy.v
Steel welded frame with high rigidity.
Motor with inverter.
Combined wet friction clutch.
Rectangular hexahedral lengthened guide; OCP-315/400 with octahedral lengthened guide.
Hydraulic overload protector.
OCP-25/45: manual adjusting, scale indicated.
OCP-45: optional elec. adjustment with digital display.
OCP-63 superior: elec. adjustment with digital display.
Lifting balance cylinder.
Imported dual solenoid valve.
Elec.forced grease lubrication.
Balance cylinder: manual oil lubrication.
Integrated panel (elec.cam included).
PLC control of international brand.
Contactor and button of international brand.
CE safety specifications
Optional: air cushion, light curtain, automotive device..
Name: Machine Body
Original: China
Heavy, one-piece welded steel frame is designed to resist deflection, providing more accurate stampings and longer die life.
Name: NC Control system
Original: Made in China
Six programmable limit switches
Four programmable die protection inputs
LCD display screen for status and fault messages
LED display for crank angle and spm
Pneumatic clutch & brake
Wet clutch and brake provide long life, very low maintenance, and high performance even at high single-stroking rates.
Use adopts dual valve from TACO, Japan, which can guarantee the safety and reliability of clutch.
Safety light curtains:
Protective fence and the safety interlock to ensure the operation safety. have a movable single-hand pedal switch, easy to operate.
Front Side Covers with safety switches, Back light safety guards (Category-4), Foot pedal conforming to CE regulation.
Control button station
Machine is with both hands button and foot switch control: anti-tie down, non-repeat controls with ring guards; conforms to
OSHA.
Specification
| Type | Throat Depth(mm) | Motor(kw) | Weight(kg) | Nomina(kn) |
| JH-21-25 | 210 | 3 | 2450 | 250 |
| JH-21-45 | 225 | 5.5 | 3550 | 450 |
| JH-21-60 | 270 | 5.5 | 5150 | 600 |
| JH-21-80 | 310 | 7.5 | 6450 | 800 |
| JH-21-100 | 330 | 7.5 | 8650 | 1000 |
| JH-21-125 | More detalis, please contact our saler, will give you best solution....... | |||
Details
- CNC or Not: Normal
- Condition: New
- Machine Type: Punching Machine
- Slide Stroke (mm): 120
- Power Source: Pneumatic
- Place of Origin: Anhui, China
- Voltage: 380V/220V Optional
- Dimension(L*W*H): 1150*900*1880mm
- Motor Power (kW): 2.2
- Model Number: JH21
- Weight (T): 2.35
- Key Selling Points: High Safety Level
- Warranty: 3 years
- Applicable Industries: Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Construction works , Energy & Mining
- Showroom Location: United Kingdom, United States
- Marketing Type: Hot Product 2019
- Machinery Test Report: Provided
- Video outgoing-inspection: Provided
- Warranty of core components: 3 years
- Core Components: Bearing, Pump, Motor
- Bolster area: 450*300mm
- Main power: Siemens Electrical
- Pneumatic component: TACO,Japan,CE
- Main Motor: Siemens Electrical
- Product name: Punching Pressing Machine
- Programmable logic controller PLC: OMRON from Japan
- Hydraulic overload: Germany
- Automatic lubrication system: Sino-Japanese joint,which has block alarm
- Type: Hydraulic Punching Press
- Brand: ACCURL
- After-sales Service Provided: Online support, Video technical support
- After Warranty Service: Video technical support, Online support
- Local Service Location: United Kingdom, United States
- Nominal Force (kN): 250
- Certification: CE ISO
