Main Structure Features:
All steel welded structure, vibrating treatment of ageing for removal of internal stress, with good rigidity and stability. Cnc control system will be used from Delem or Cybelec, servo motors and driver are imported brand; electric parts: siemens or Te Lower working tables fitted with hydraulic crowning system
Characteristics:
1 Two cylinder to control the movement of the ram
2 Mechanical torsion synchrony
3 The vibration aging othermeasuring eliminating stress, machine good strength
4 Domestic fabricated digital display unit
5 Domestic famous hydraulic integrated system
6 With CHINT or Siemens LV electrical apparatus
7 Rotary encoder feedback equipment
8 Imported sealing enclose
9 Type-T screw mandrel to control the movement of back gauge
10 Stand connect die and too(with upper-tilted block compensation unit)
11 Standard front support sheet frame
Specification
| NO. | Name | 110/3100 | 160/3100 | Unit | Remarks |
| 1 | Normal force | 1100 | 1600 | KN | |
| 2 | Worktable length | 3100 | 3100 | mm | |
| 3 | Distance between uprights | 2600 | 2600 | mm | |
| 4 | Ram stroke | 200 | 200 | mm | |
| 5 | Max. opening height | 500 | 500 | mm | |
| 6 | Throat depth | 400 | 400 | mm | |
| 7 | CNC axis | 3 1 | 3 1 | axis | Y1,Y2,X V |
| 8 | Main motor power | 11 | 15 | KW | |
| 9 | Oil cylinder | 2 | 2 | pieces | |
| 10 | Approx. weight | 7800 | 9800 | kg |
Packing & Delivery
We choose the best packaging, the most excellent logistics services, to ensure that your goods faster and safer to reach the destination.
FAQ
Q. What are your normal lead times?
A. Our company typical lead times range from 3-4weeks after receipt of order.
Q. What are the terms of payments you offer?
A. We accept payment of T/T, L/C, and Western Union, cash, O/A etc.
Q. What kind of package do you offer?
A. Normally in plywood case, to make sure all goods in good condition.
Q. What is the MOQ for your production?
A. The MOQ depends on your requirements for color, logo and so on. For some normal items, we have in stock, the MOQ is 1 set.
Q. Do you have CE certification
A. Yes, we have CE certification, machine quality is one year guaranteed.
Q. How to control the quality of the products?
A. We have always placed great emphasis on the quality level is maintained. Moreover, the principle we always maintain is "to provide customers better quality, better price, and better service"
Details
- Slider Stroke (mm): 180 mm
- Automatic Level: Semi-automatic
- Throat Depth (mm): 400 mm
- Machine Type: Synchronized, Press Brake
- Length of Working Table (mm): 3200 mm
- Width of Working Table (mm): 400 mm
- Condition: New
- Material / Metal Processed: Stainless Steel
- Automation: Automatic
- Extra Services: bending
- Weight (KG): 8700
- Motor Power (kw): 11 kw
- Key Selling Points: Competitive Price
- Warranty: 1 Year
- Applicable Industries: Manufacturing Plant
- Showroom Location: Egypt
- Marketing Type: New Product 2020
- Machinery Test Report: Provided
- Video outgoing-inspection: Provided
- Warranty of core components: 1 Year
- Core Components: Motor, PLC, Gearbox
- After-sales Service Provided: Engineers available to service machinery overseas, Field installation, commissioning and training
- Raw Material: Sheet / Plate Rolling
- Power: CNC
- name: most popular hydraulic CNC press brake
- cnc control system: Holland delem's DA65W
- Certification: ce
- After Warranty Service: Field maintenance and repair service
