Adopt hydraulic driving system and various metal plate, square bar, round bar, angel, channel and joist can be cut, punched and notched.
Characteristic
1. The design of this machine adopts four column and three plate type open space, with high down pressure stability.
2. Large worktable, suitable for the installation of large mold.
3. The oil pressure circuit design is simple, the motor force demand is small, and the maintenance is easy.
4. Under the table are equipped with wheel seat, portable mobile machine, labor saving, high efficiency.
5. It can be operated by both hands and protected by rapid rising.
6. It can be equipped with rotary indexing plate and automatic feeding and returning device.
Specifcation
| Specification | Model | 10601 | 10603 |
| PS55 | PS110 | ||
| Pressure | 55 | 110 | |
| Max.cutting tickness | 16 | 25 | |
| Plate strength | <450 | <45 | |
| Cutting angle | 7 | 8 | |
| Shearing size of one stroke | 16*250 /8*400 | 25*300 /16*600 | |
| Ram stroke | 80 | 80 | |
| Number of strokes | 8 | 6 | |
| Throat thickness | 300 | 400 | |
| Pumching thickness | 16 | 25 | |
| Max.Puching diameter | 25 | 35 | |
| Power of main motor | 4 | 7.5 | |
| Over al dimensions(L*W*H) | 1640*730*1770 | 2355*960*2090 | |
| Weight of machine | 1600 | 4800 | |
FAQ
Q. What are your normal lead times?
A. Our company typical lead times range from 3-4weeks after receipt of order.
Q. What are the terms of payments you offer?
A. We accept payment of T/T, L/C, and Western Union, cash, O/A etc.
Q. What kind of package do you offer?
A. Normally in plywood case, to make sure all goods in good condition.
Q. What is the MOQ for your production?
A. The MOQ depends on your requirements for color, logo and so on. For some normal items, we have in stock, the MOQ is 1 set.
Q. Do you have CE certification
A. Yes, we have CE certification, machine quality is one year guaranteed.
Q. How to control the quality of the products?
A. We have always placed great emphasis on the quality level is maintained. Moreover, the principle we always maintain is "to provide customers better quality, better price, and better service
Details
- CNC or Not: Normal
- Condition: New
- Nominal Force (kN): 55
- Power Source: Hydraulic
- Dimension(L*W*H): 1640*730*1770mm
- Weight (T): 1.6
- Key Selling Points: High-accuracy
- Warranty: 1 Year
- Showroom Location: Egypt, Canada, Algeria
- Applicable Industries: Manufacturing Plant, Machinery Repair Shops, Building Material Shops
- Function: Steel Metal Punching
- Color: Customizable
- Material: Steel Material
- Electric parts: SCHNEIDER
- Cutting Material: Metal Stainless Steel Carbon Steel
- Certification: CE ISO, ISO9001
- After-sales Service Provided: Free spare parts, Online support, Field maintenance and repair service, Video technical support, Field installation, commissioning and training
- After Warranty Service: Video technical support, Field maintenance and repair service, Spare parts, Online support
- Local Service Location: Algeria, Egypt, Canada
