Product Description
This machine has advanced technology and reliable performance, which makes it ideal equipment for sheet forming. It is widely used in many industries, such as plane, automobile, ship, electronics, machinery and light industry, with high production efficiency.
The whole machine is welding constructed up with steel sheets. It has enough strength and toughness. Hydraulic drive can prevent serious over-load accident due to the change of sheet thickness or incorrect position of lower die V slot. Furthermore, it works stably and reliably with easy operation. It also has the functions like inching movement, single movement and continuous movement. Especially it has equal pressure during the whole working process. Compensation mechanism is installed upon the upper die, which insures high bending precision. As long as users use different dies, it can bend metal sheet into different shapes. When equipped with relevant outfits, it can also be used to bend pipe and punch.
| SPECIFICATIONS | ||||||
| Model(WD67Y) | Normal Force(KN) | Worktable Length(MM) | Distance Btw. Housing(MM) | Throat Depth(MM) | Ram Stroke(MM) | MotorPower (KW) |
| 30T/1600 | 300 | 1600 | 1300 | 220 | 80 | 3 |
| 35T/2050 | 350 | 2050 | 1600 | 220 | 100 | 4 |
| 40T/2200 | 400 | 2200 | 1850 | 200 | 100 | 5.5 |
| 40T/2500 | 400 | 2500 | 2000 | 200 | 100 | 5.5 |
| 63T/2500 | 630 | 2500 | 2000 | 250 | 125 | 5.5 |
| 63T/3200 | 630 | 3200 | 2560 | 250 | 125 | 5.5 |
| 80T/2500 | 800 | 2500 | 2000 | 320 | 140 | 7.5 |
| 80T/3200 | 800 | 3200 | 2560 | 320 | 140 | 7.5 |
| 80T/4000 | 800 | 4000 | 2960 | 320 | 140 | 7.5 |
| 100T/2500 | 1000 | 2500 | 2000 | 320 | 140 | 7.5 |
| 100T/3200 | 1000 | 3200 | 2560 | 320 | 140 | 7.5 |
| 100T/4000 | 1000 | 4000 | 2960 | 320 | 140 | 7.5 |
| 125T/3200 | 1250 | 3200 | 2560 | 320 | 125 | 7.5 |
| 125T/4000 | 1250 | 4000 | 2960 | 320 | 125 | 7.5 |
| 160T/3200 | 1600 | 3200 | 2550 | 320 | 200 | 11 |
| 160T/4000 | 1600 | 4000 | 2950 | 320 | 200 | 11 |
| 160T/5000 | 1600 | 5000 | 3950 | 320 | 200 | 11 |
| 200T/3200 | 2000 | 3200 | 2540 | 320 | 200 | 15 |
| 200T/4000 | 2000 | 4000 | 2940 | 320 | 200 | 15 |
| 200T/5000 | 2000 | 5000 | 3940 | 320 | 200 | 15 |
| 250T/4000 | 2500 | 4000 | 2920 | 400 | 250 | 18.5 |
| 250T/5000 | 2500 | 5000 | 3920 | 400 | 250 | 18.5 |
| 300T/4000 | 3000 | 4000 | 2920 | 400 | 250 | 18.5 |
| 300T/5000 | 3000 | 5000 | 3920 | 400 | 250 | 18.5 |
| 300T/6000 | 3000 | 6000 | 4920 | 400 | 250 | 18.5 |
| Note: please conact our sales personel for other technical details. | ||||||
Main Features
1. Machine Charactristcs
- The machine is equipped with hydraulic electric control, freely adjustable slider travels and inching, semi-automatic, automatic operating criterion convenient for module trial and adjustment.
- Up-move type bending design,pair oil cylinders working simultaneously, balanced operation,convenient,and safety.
- With function of keeping pressure and delay time on lower dead spot, to assure the accuracy of work pieces.
- Under the national standard conditions, the accuracy of bending angle can up to ±45´.
- With function of slow decline, operator can control work pieces better.
2. Hydraulic system
- Hydraulic system may realize quick decline, slow decline, working speed bending, quick return travel and sudden slider stop in the process of up and down etc.
- Quality pump can stand high pressure, and low noise.
- Sealing rings from Japanese NOK, with good sealing performance, reliable working, and long life.
- The machine can work continuously under rated burden, hydraulic system has no divulgence, continue and steady, high accuracy.
3. Standard equipped with NC Controller (E21)
- ESTUN E21 is a simple CNC control system designed to replace ESTUN E200 with lower price.
- ESTUN is jointed company by HOLLAND DELEM AND CHINA ESTUN
- ESTUN E21can control X axis working into position accurately
- ESTUN E21 will work better accompany with FREQUENCY TRANSFORMER. FREQUENCY TRANSFORMER is not the standard components, optional.
- Can program the software for future usage and has memory
- Programmable 40 Jobs, each job has 25 Steps;
- Can set up different steps in one program.
- Timer can control the bending time
- Control X/Y two axis
Optional Controller:
Estun-E200,E210; Delem-DA41; Cybelc-Cybertouch 6; Wonder-ENC600.
Our Service
- Price: Give me reply, i will give you my favorable price immediately!
- Payment term: 30% deposit and the balance paid against copy of B/L in 3 days.
- Package: Standard exporting package.
- Operation manual and video disc: When delivery machine, the related operation instruction of model will delivery together with machine. And in the instruction, there is teaching video disc.
After-sales service:
1. machine is simple, generally, user can understand how to operate. There is operation instruction and disc.
2. welcome to our factory to learn how to operate our machine, we will give good training.
3. our engineer is available for user. If there is requirement, our engineer can go to user factory, and adjust machine, give good training to user.
Details
- Slider Stroke (mm): 200 mm
- Automatic Level: Semi-automatic
- Throat Depth (mm): 250 mm
- Machine Type: Synchronized
- Length of Working Table (mm): 2500
- Width of Working Table (mm): 400 mm
- Condition: New
- Place of Origin: Anhui, China
- Material / Metal Processed: Brass / Copper, Stainless Steel, ALLOY, Carbon steel, Aluminum, Plastic
- Automation: Automatic
- Extra Services: End Forming
- Weight (KG): 4800
- Motor Power (kw): 7.5 kw
- Key Selling Points: High Productivity
- Warranty: 1 Year
- Applicable Industries: Building Material Shops, Manufacturing Plant, Construction works , Energy & Mining
- Showroom Location: None
- Marketing Type: New Product 2020
- Machinery Test Report: Provided
- Video outgoing-inspection: Provided
- Warranty of core components: 2 years
- Core Components: Bearing, Gear, Engine
- Certification: ce
- After-sales Service Provided: Online support
- After Warranty Service: Video technical support, Online support, Spare parts, Field maintenance and repair service
